Description
Overview
The ALPHA 3 family packs about 3.8 to 4kWh into a single 12V battery, so one battery can do the work of three 100Ah batteries. All versions use Grade A+ LiFePO4 cells, an IP65 housing with a UL94 V-0 flame-retardant shell, and connect up to four in parallel.
The LITE is the value pick without heating or Bluetooth. The ALPHA 3 adds internal heating and Bluetooth. The PRO has the longest cycle rating and UL 1973 certification. The MINI is about 40% smaller in volume than standard 12V 314Ah batteries.
Who it’s for
- RVs and vans that need a lot of 12V storage.
- Off-grid cabins.
- Home backup systems on a 12V inverter.
Key benefits
- Huge 12V capacity: up to 4,019Wh per battery.
- Four versions: pick the features you need.
- IP65: dust and water resistant.
- Expandable: up to 4 in parallel.
Compare the ALPHA 3 versions
| Version | Capacity | Cycles | Heating and Bluetooth | Size and weight |
|---|---|---|---|---|
| ALPHA 3 LITE | 300Ah / 3,840Wh | 4,000+ | No | 20.6 x 10.6 x 8.7 in, 71.3 lb |
| ALPHA 3 | 300Ah / 3,840Wh | 5,000+ | Yes | 20.6 x 10.6 x 8.7 in, 71.7 lb |
| ALPHA 3 PRO | 314Ah / 4,019Wh | 8,000+ | Yes | 20.5 x 10.6 x 8.7 in, 71.7 lb |
| ALPHA 3 MINI | 314Ah / 4,019Wh | 5,000+ | Yes (100W heater) | 15.1 x 7.6 x 9.9 in, 61.7 lb |
Figures are Rich Solar’s current specifications for each version.
Specifications
| Voltage | 12.8V |
|---|---|
| Chemistry | LiFePO4, Grade A+ cells |
| Max charge / discharge | 300A (LITE, ALPHA 3); 200A (PRO, MINI) |
| Parallel | Up to 4 |
| Charge temperature | 32°F to 131°F |
| Discharge temperature | -4°F to 140°F |
| IP rating | IP65 |
FAQ
Which version should I choose?
Choose the ALPHA 3 or PRO if you’ll charge below freezing. Choose the MINI if space is tight. The LITE suits warm climates and tight budgets.
Why do the PRO and MINI say 314Ah?
That’s Rich Solar’s current rating for those versions, which uses larger 314Ah cells.
Warranty
Manufacturer’s warranty: 5 years (ALPHA 3 LITE, ALPHA 3, ALPHA 3 MINI); 10 years (ALPHA 3 PRO). Original purchaser only. Source: Rich Solar warranty.
Defective on arrival or within 30 days? You can also return it to us under our Returns & Refunds Policy. See how warranty claims work.
